MCC56-12io8B PDF Download |
|
File Size : 116 KB
Manufacturer:IXYS Description:The feedback network provides a closed loop gain of 1 000 and the integrator time constant serves to reduce noise at the output of the test circuit as well as allowing the output of the device under test to remain near zero volts The bias current test is accomplished by allowing the device under test to draw input current to one of its inputs through the corresponding input resistor on positive going or nega- tive going halves of the triangular wave generator output This is accomplished by closing S5a or S5b on alternate halves of the triangular wave input The voltage appearing across the input resistor is equal to input current times the input resistor This voltage is multiplied by 1 000 by the feedback loop and appears at the integrator output and the vertical input of the oscilloscope The vertical separaton of the traces representing the two input currents of the amplifi- er under test is equivalent to the total bias current of the amplifier under test The bias current over the entire common mode range may be examined by setting the output of A8 equal to the amplifi- er common mode range A photograph of the bias current oscilloscope display is given as Figure 2 In this figure the total input current of an amplifier is displayed over a g10V common mode range with a sensitivity of 100 nA per vertical division |
|
