| MCD56-12io8B资料 | |
|
MCD56-12io8B PDF Download |
|
File Size : 116 KB
Manufacturer:IXYS Description:The MAX1737 EV kit is a fully assembled and tested surface-mount board. Follow the steps below to verify board operation. Do not turn on the power supply until all connections are completed. Observe all pre- cautions on the battery manufacturers data sheet. Use only lithium-ion cells with this charger: 1) Set jumper JU6 to indicate the number of cells in the battery pack (Table 1). 2) Place a shunt on jumper JU1 to disable the temper- ature monitoring function. 3) Place a shunt across pins 1-2 on JU2 to enable the MAX1737. 4) Place a shunt across JU3 to enable 2A charging current limit. 5) Place a shunt across JU4 to enable 2A input current limit. 6) Remove any shunt from JU5 to set the cell voltage to 4.2V. If a different battery regulation voltage is required, refer to the MAX1737 data sheet. 7) Connect a +7VDC to +28VDC power supply with sufficient power rating across the VIN and GND pads. 8) Connect a lithium-ion battery pack between the BATT+ and BATT- pads. 9) Turn on the power supply. 10) Measure the battery voltage and verify that the LEDs indicate the correct state. |
|
